Hydraulic Punch Press Machine

Name :Hydraulic punch press machine Brand :Rbqlty Item NO :1523955521 Category :PUNCH PRESS MACHINE Model Type :Y32-Y27-Y28 Price :CONSULT

关键词：

key word:

Laser cutting machine | Bending machine

Category:

Phone：

Product Description
Components
Technical Parameters

- Commodity name: Hydraulic Punch Press Machine
- Commodity ID: 1056961561186099200
Name :Hydraulic punch press machine Brand :Rbqlty Item NO :1523955521 Category :PUNCH PRESS MACHINE Model Type :Y32-Y27-Y28 Price :CONSULT

Hydraulic press machine for deep drawing, bending, hemming, cold extrusion, stamping, blanking

1.Main introduction

Three beam four-column structures, after the computer optimized design, simple, economic, and apply. Hydraulic control system uses an integrated cartridge valve systems and reliability, long service life, hydraulic shock is small, reduces piping and leak-point links. It has stand-alone electrical control system which is reliable, intuitive motion and easy for maintenance.

2.Applications

This series of presses are for metal materials, deep drawing, bending, hemming, cold extrusion, stamping, blanking and other craft, also applies to the correction, press-fit, powder products, abrasive products, as well as the suppression of molding plastic products, insulation materials, repression of molding.it can make below products：

Household appliance: washing machine, TV, refrigerator, air conditioning, rice cooker and other parts.

Kitchenware: sink, tea set and Other kinds of containers.

Auto parts: automobile body covering parts, braking, fuel tanks, chassis, axle case, bumper.

3. Optional Accessories

blanking buffer devices, mobile platforms, light curtain safety protection device, oil cooling device, touch-screen industry, playing material device (hydraulic or mechanical type), die fast clamping structure, import PLC , change mode to use floating rails and rolling bracket, mounted on a hydraulic system, slider locking mechanism

4.Working environment

Temperature: 0°C - 40°C2. Humidity: relative humidity is under 90%.3. Voltage: 380V(-15%,+15%),3P,50Hz

Main structure of machine

1. hydraulic power part - manual and electric

2. Mechanical control

3. Working oil cylinder part

4. The hydraulic power part consists of hydraulic oil pump, motor with elastic coupling and connecting plunger pump

5. The mechanical control part is controlled by the distribution box and the combination button switch

6. oil pipe is connected by the high pressure seamless steel tube

Main components

Transformer: Simens

Middle relay: Simens

Time relay: Simens

Breaker: Simens

Thermal relay: Simens

Oil pump: 25YCY14-1B Chinese famous brand

Main motor: Simens

Valves: TAIFENG

Seals: PARKER

Buttons: Simens

PLC: Mistsubushi

Security protection

Beam upper limited is protected by the light curter

With “PAUSE” & “EMERGENCY STOP” button.

With Second supporting loop for the main cylinder

Security valve for hydraulic loop

The hydraulic system

The hydraulic system is composed of energy conversion device, energy regulation control device and hydraulic

accessories, and through the control of electrical system, the circulation of various actions is completed.The tubing of the

hydraulic system is connected by high pressure flange.

Electrical control system

Electrical control system is divided into dynamic system and control system part of electric control system of the press used in

PLC programmable controller and the black silk ribbon touch screens and centralized control temperature module, which can

realize machine all kinds of craft operating cycle.

Mode of operation

The equipment has adjustment (inching), semi-automatic two kinds of process action selection.

Mode of operation
