6+1 Axis DA52S DA66T CNC Press Brake Machine

Name : 6+1 Axis DA52S DA66T CNC Press Brake Machine Brand :Rbqlty Category :CNC PRESS BRAKE MACHINE Model Type :WE67K Price: CONSULT

关键词：

key word:

Laser cutting machine | Bending machine

Category:

Phone：

Product Description
Components
Technical Parameters

- Commodity name: 6+1 Axis DA52S DA66T CNC Press Brake Machine
- Commodity ID: 1056960449758453760
Name : 6+1 Axis DA52S DA66T CNC Press Brake Machine Brand :Rbqlty Category :CNC PRESS BRAKE MACHINE Model Type :WE67K Price: CONSULT

DA66T CNC press brake machine Max 8 axis Y1.Y2.X1.X2.Z1.Z2.R1.R2

DA-66T offers 2D programming which includes automatic bend sequence calculation and collision detection functions. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling. The touch screen gives access to the proven Delem user-interface and enables direct navigation between programming and production. Functions are directly located where you need them, offering optimized ergonomics throughout the application.

Standard:

1. 2D graphical touch screen.

2. 3D visualization in simulation and production.

3. 17" color LCD display. (TFT)

4. Standard Windows functions. User specific applications support.

5. USB keyboard, mouse and flash memory drive.

6. Emergency stop device.

7. German ROSCH-REXROTH or HOERBIGER hydraulic circuit.

8. Equipped with European optical scales.

9. Precision ball screw lead, linear slide way and AC servo motor for X axis.

10. Bearing-type guideway system.

Main Function:

11. Alphanumeric product naming.

12. Automatic bending sequences calculation and setting.

13. Multi-aspect programming, graphics programming, data programming and one page programming table.

14. Millimetres/Inches, KN/Ton and languages selection.

15. Programmable material properties and axes speed.

16. Bend sequences and real-scale tooling visualization while bending.

17. Computed functions include tooling safety zones, press force, crowning adjustment, developed length, axes position, operation modes and etc.

18. Step repeat up to 99 (maximum).

19. Error messaging system.

20. Hand-wheel movement of all axes.
Holland CNC systems:

DA52S X Y1 Y2 (R V)

DA53T X Y1 Y2 (R V) + Touch Screen

DA58T X Y1 Y2 (R V) + Touch Screen + 2D programming

DA66T X Y1 Y2 (R1 R2 Z1 Z2 V) + Touch Screen + 3D programming

Product Description

DA66T CNC press brake machine Max 8 axis Y1.Y2.X1.X2.Z1.Z2.R1.R2

DA-66T offers 2D programming which includes automatic bend sequence calculation and collision detection functions. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling. The touch screen gives access to the proven Delem user-interface and enables direct navigation between programming and production. Functions are directly located where you need them, offering optimized ergonomics throughout the application.

Standard:

1. 2D graphical touch screen.

2. 3D visualization in simulation and production.

3. 17" color LCD display. (TFT)

4. Standard Windows functions. User specific applications support.

5. USB keyboard, mouse and flash memory drive.

6. Emergency stop device.

7. German ROSCH-REXROTH or HOERBIGER hydraulic circuit.

8. Equipped with European optical scales.

9. Precision ball screw lead, linear slide way and AC servo motor for X axis.

10. Bearing-type guideway system.

Main Function:

11. Alphanumeric product naming.

12. Automatic bending sequences calculation and setting.

13. Multi-aspect programming, graphics programming, data programming and one page programming table.

14. Millimetres/Inches, KN/Ton and languages selection.

15. Programmable material properties and axes speed.

16. Bend sequences and real-scale tooling visualization while bending.

17. Computed functions include tooling safety zones, press force, crowning adjustment, developed length, axes position, operation modes and etc.

18. Step repeat up to 99 (maximum).

19. Error messaging system.

20. Hand-wheel movement of all axes.
